Description
Filter inside:
External filter P604457
Internal filter P603729
Cross Reference
DONALDSON FKB045008
HIFI FILTER SAH01C05ADP003
THWAITES T102629
Parameter
Outlet Diameter: 50.8 mm (2.00 inch)
Inlet Diameter: 50.8 mm (2.00 inch)
Body Diameter: Maximum 132.9 mm (5.23 inch)
Overall Length: 342.4 mm (13.48 inch)
Body Length: 265.6 mm (10.46 inch)
Rated Flow LR: 2 m³/min (71 cfm)
Rated Flow MR: 2.4 m³/min (85 cfm)
Rated Flow HR: 2.7 m³/min (95 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Family: FKB
Brand: Cycloflow™
Packaged Dimensions
Packaged Length: 26.16 cm (10.30 inch)
Packaged Width: 20.07 cm (7.90 inch)
Packaged Height: 44.20 cm (17.40 inch)
Packaged Weight: 1.26 kg (2.78 lb)
Packaged Volume: 0.02 m3 (0.82 ft3)
