Description
Filter inside:
External filter P611859
Internal filter P602427
Cross Reference
ASV INCORPORATED 2052291
Parameter
Outlet Diameter: 63.4 mm (2.50 inch)
Inlet Diameter: 63.5 mm (2.50 inch)
Body Diameter: Maximum 151.1 mm (5.95 inch)
Overall Length: 401.5 mm (15.81 inch)
Body Length: 326 mm (12.83 inch)
Rated Flow LR: 3.3 m³/min (117 cfm)
Rated Flow MR: 3.9 m³/min (138 cfm)
Rated Flow HR: 4.4 m³/min (155 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Family: FKB
Brand: Cycloflow™
Packaged Dimensions
Packaged Length: 26.16 cm (10.30 inch)
Packaged Width: 20.32 cm (8.00 inch)
Packaged Height: 44.45 cm (17.50 inch)
Packaged Weight: 1.52 kg (3.35 lb)
Packaged Volume: 0.02 m3 (0.83 ft3)
