Description
Use With CLAMP P115204
Cross Reference
BALDWIN PA3867
BIG A 93326
CARQUEST 87326
CATERPILLAR 312126
CATERPILLAR 3I2126
CUMMINS 3924540
DONALDSON ECB085024
DONALDSON ECB085046
FLEETGUARD AH19002
FLEETRITE AHR819002
HIFI FILTER SAB085046
NAPA 2326
SAKURA AH5705
SF FILTER SL12903
SF FILTER SL12945
VMC AH85046
WIX 42326
Parameter
Outlet Diameter: 101.6 mm (4.00 inch)
Body Diameter: Maximum 216 mm (8.50 inch)
Body Length: 279 mm (10.98 inch)
Efficiency Test Std: ISO 5011
Rated Flow LR: 7.9 m³/min (279 cfm)
Rated Flow MR: 11.3 m³/min (399 cfm)
Rated Flow HR: 13.3 m³/min (470 cfm)
Restriction: LR: 10 mbar (4.02 inch H2O)
Restriction: MR: 14.91 mbar (5.98 inch H2O)
Restriction: HR: 19.91 mbar (7.99 inch H2O)
Family: ECB
Type: Primary
Style: Round
Brand: DuraLite™
Media Type: Cellulose
Packaged Dimensions
Packaged Length: 22.86 cm (9.00 inch)
Packaged Width: 22.86 cm (9.00 inch)
Packaged Height: 33.02 cm (13.00 inch)
Packaged Weight: 1.71 kg (3.77 lb)
Packaged Volume: 0.02 m3 (0.60 ft3)
