Description
Use With CLAMP P115204
Cross Reference
AC DELCO A1474C
AIR REFINER ARM 08 5011
BALDWIN PA2818
BALDWIN PA2820
BIG A 93790
CARQUEST 87790
CARQUEST 88637
CATERPILLAR 3I0005
CUMMINS 1403597
CUMMINS 3912020
CUMMINS 3912986
DONALDSON B085011
DONALDSON ECB085011
FLEETGUARD AH1141
FLEETGUARD AH19037
FLEETRITE AHR 81141
FLEETRITE AHR819037
FORD 9576B105006
FRAM CA6818
FREIGHTLINER DNB105006
HASTINGS AF1012
HASTINGS AF2329
HAVAM HD1925
HIFI FILTER SAB105006
JOHN DEERE RE47573
KIRLOSKAR 6H112801000
KRALINATOR LA1458
KRALINATOR LA1459R
LUBER FINER LAF2531
LUBER FINER LAF2533
NAPA 2790
NAPA 6637
SAKURA AH5707
SCANIA 1394527
SCHUPP SL12906
SDMO 330560556
TIPPECANOE B08 5011
VMC AH105006
WIX 42790
Parameter
Outlet Diameter: 102 mm (4.02 inch)
Body Diameter: Maximum 266.7 mm (10.50 inch)
Body Length: 266.7 mm (10.50 inch)
Efficiency 99.9
Efficiency Test Std: ISO 5011
Rated Flow LR: 12.7 m³/min (448 cfm)
Rated Flow MR: 16.7 m³/min (590 cfm)
Rated Flow HR: 19.2 m³/min (678 cfm)
Restriction: LR: 10 mbar (4.02 inch H2O)
Restriction: MR: 14.91 mbar (5.98 inch H2O)
Restriction: HR: 19.91 mbar (7.99 inch H2O)
Family: ECB
Type: Primary
Style: Round
Brand: DuraLite™
Media Type: Cellulose
Packaged Dimensions
Packaged Length: 27.43 cm (10.80 inch)
Packaged Width: 27.69 cm (10.90 inch)
Packaged Height: 32.51 cm (12.80 inch)
Packaged Weight: 2.14 kg (4.71 lb)
Packaged Volume: 0.02 m3 (0.87 ft3)
