Description
Filter inside:
External filter P181028
Internal filter P137640
Cross Reference
BALDWIN PA2521
CARQUEST 87253
FLXIBLE 87092700001
FORD 9576B120271
FREIGHTLINER DNB120271
HOBART 286061
HURRICANE COMPRESSOR 62801
NEOPLAN BX0203001
WIX 42253
Parameter
Outlet Diameter: 127 mm (5.00 inch)
Inlet Diameter: 139.7 mm (5.50 inch)
Body Diameter: Maximum 299.97 mm (11.81 inch)
Overall Length: 467.87 mm (18.42 inch)
Body Length: 403.35 mm (15.88 inch)
Rated Flow LR: 17.6 m³/min (622 cfm)
Rated Flow MR: 20.7 m³/min (731 cfm)
Rated Flow HR: 22.6 m³/min (798 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Family: EBB
Packaged Dimensions
Packaged Length: 53.09 cm (20.90 inch)
Packaged Width: 35.31 cm (13.90 inch)
Packaged Height: 51.05 cm (20.10 inch)
Packaged Weight: 9.88 kg (21.77 lb)
Packaged Volume: 0.09 m3 (3.38 ft3)
