Description
Use With CLAMP P115208
Cross Reference
BALDWIN PA30010
HIFI FILTER SAB120376
KOHLER 10801001001
LOESING 020960
MTU 10801001001
MTU X59612100003
Parameter
Outlet Diameter: 197.7 mm (7.78 inch)
Body Diameter: Maximum 317.5 mm (12.50 inch)
Body Length: 400 mm (15.75 inch)
Efficiency Test Std: ISO 5011
Rated Flow LR: 30 m³/min (1059 cfm)
Rated Flow MR: 36.9 m³/min (1303 cfm)
Rated Flow HR: 42.5 m³/min (1501 cfm)
Restriction: LR: 10 mbar (4.02 inch H2O)
Restriction: MR: 14.91 mbar (5.98 inch H2O)
Restriction: HR: 19.91 mbar (7.99 inch H2O)
Family: ECB
Type: Primary
Style: Round
Brand: DuraLite™
Packaged Dimensions
Packaged Length: 33.28 cm (13.10 inch)
Packaged Width: 32.51 cm (12.80 inch)
Packaged Height: 50.29 cm (19.80 inch)
Packaged Weight: 3.70 kg (8.15 lb)
Packaged Volume: 0.05 m3 (1.92 ft3)
