Description
Use With CLAMP P115206
Cross Reference
AIR MAZE SEFB1251
AIR SUPPLY 121804
BALDWIN PA2821
CASE/CASE IH NB125003
CATERPILLAR 3I0006
FLEETGUARD AF19042
FLEETGUARD AH19042
GENERAC B125003
GENERAL MOTORS 25313792
HAVAM HD1930
HIFI FILTER SAB125003
JOY 5190020034
LUBER FINER LAF9541
LUBER FINER LAF9541001527767
SCHUPP SL12908
VMC AF125003
WALGAHN MOTORENTECHN 00810032
WALGAHN MOTORENTECHN 810032
WOODGATE WGA1146
Parameter
Outlet Diameter: 152.4 mm (6.00 inch)
Body Diameter: Maximum 318 mm (12.52 inch)
Body Length: 381 mm (15.00 inch)
Efficiency Test Std: ISO 5011
Rated Flow LR: 23.5 m³/min (830 cfm)
Rated Flow MR: 31.4 m³/min (1109 cfm)
Rated Flow HR: 36.7 m³/min (1296 cfm)
Restriction: LR: 10 mbar (4.02 inch H2O)
Restriction: MR: 14.91 mbar (5.98 inch H2O)
Restriction: HR: 19.91 mbar (7.99 inch H2O)
Family: ECB
Type: Primary
Style: Round
Brand: DuraLite™
Media Type: Cellulose
Packaged Dimensions
Packaged Length: 32.51 cm (12.80 inch)
Packaged Width: 32.26 cm (12.70 inch)
Packaged Height: 43.43 cm (17.10 inch)
Packaged Weight: 4.19 kg (9.23 lb)
Packaged Volume: 0.05 m3 (1.61 ft3)
