Description
Use With CLAMP P115205
Cross Reference
BALDWIN PA30125
CARQUEST 83011
CARQUEST 93670
FLEETGUARD AH8513
GRAINGER 52AZ65
HAVAM HD1938
HENGST E789L
HIFI FILTER SAB125011
HIMOINSA 3033342
LOESING 020125
LOESING 20125
MTU 0170942502
MTU 13125011
NAPA GOLD 9011
SAUER DANFOSS INC 11049982
SCANIA 1332341
SCHUPP SL12910
SF FILTER SL12910
SULLAIR B125011016140
WALGAHN MOTORENTECHNIK 00811776
Parameter
Outlet Diameter: 127 mm (5.00 inch)
Body Diameter: Maximum 317.5 mm (12.50 inch)
Body Length: 228.1 mm (8.98 inch)
Efficiency Test Std: ISO 5011
Rated Flow LR: 19.8 m³/min (699 cfm)
Rated Flow MR: 25 m³/min (883 cfm)
Rated Flow HR: 29 m³/min (1024 cfm)
Restriction: LR: 10 mbar (4.02 inch H2O)
Restriction: MR: 14.91 mbar (5.98 inch H2O)
Restriction: HR: 19.91 mbar (7.99 inch H2O)
Family: ECB
Type: Primary
Style: Round
Brand: DuraLite™
Packaged Dimensions
Packaged Length: 31.75 cm (12.50 inch)
Packaged Width: 31.75 cm (12.50 inch)
Packaged Height: 30.99 cm (12.20 inch)
Packaged Weight: 2.85 kg (6.29 lb)
Packaged Volume: 0.03 m3 (1.10 ft3)
