Description
Filter inside: P181015
Cross Reference
ACDELCO A784C
AIR REFINER ARM129544
AMERICAN PARTS 1377
AV TECHNOLOGY 100690
BALDWIN PA2525
BIG A FILTER 1377
BOMBARDIER 114647200
BOWES LAF9544
CANADIAN FILTER CO. CFM881
CARQUEST 87491
CASE 1674320C2
CATERPILLAR 310773
FLXIBLE 87088900003
GILLIG 8237300000
HOBART 408592
HURRICANE COMPRESSOR 62394
INTERNATIONAL 533770C91
IRKARUS 436001530900
MI JACK 43161002
MIJACK 43161002
NAVISTAR 533770C91
NEOPLAN LG0203001
PREVOST CAR 19500760
PRINOTH 114647200
WIX 42491
Parameter
Outlet Diameter: 152.4 mm (6.00 inch)
Inlet Diameter: 177.8 mm (7.00 inch)
Body Diameter: Maximum 355.6 mm (14.00 inch)
Overall Length: 511.05 mm (20.12 inch)
Body Length: 428.24 mm (16.86 inch)
Rated Flow LR: 25.5 m³/min (901 cfm)
Rated Flow MR: 29.7 m³/min (1049 cfm)
Rated Flow HR: 37.4 m³/min (1321 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Family: EBB
Packaged Dimensions
Packaged Length: 60.71 cm (23.90 inch)
Packaged Width: 44.70 cm (17.60 inch)
Packaged Height: 51.05 cm (20.10 inch)
Packaged Weight: 14.01 kg (30.85 lb)
Packaged Volume: 0.14 m3 (4.89 ft3)
