Description
Filter inside:
External filter P777871
Internal filter P777875
Or filter kit X011344
Cross Reference
CASE 02888430
CASE 2888430
CATERPILLAR 3711799
DONALDSON ERB150025
HIFI FILTER SAH01C15ADH001
LAVERDA 322826450
LAVERDA LA322826450
LOESING 020701
SULLAIR 02250146413
SULLAIR 2250146413
Parameter
Outlet Diameter: 178 mm (7.01 inch)
Inlet Diameter: 178 mm (7.01 inch)
Body Diameter: Maximum 381 mm (15.00 inch)
Overall Length: 660 mm (25.98 inch)
Length: 590 mm (23.23 inch)
Body Length: 513.5 mm (20.22 inch)
Inlet Length: 241.5 mm (9.51 inch)
Outlet Length: 70 mm (2.76 inch)
Service Clearance 540 mm (21.26 inch)
Family: ERB
Inlet Location 136 mm (5.35 inch)
Packaged Dimensions
Packaged Length: 43.00 cm (16.93 inch)
Packaged Width: 51.00 cm (20.08 inch)
Packaged Height: 72.01 cm (28.35 inch)
Packaged Weight: 14.00 kg (30.87 lb)
Packaged Volume: 0.16 m3 (5.58 ft3)
