Description
Use with COVER ASSEMBLY P784869
Cross Reference
AGCO LA323127600
CASE/CASE IH 02888430
CASE/CASE IH 2888430
CUMMINS CDD000551
DONALDSON ERB150058
HIFI FILTER SAH01C15ADH002
LAVERDA 323127600
LOESING 20701
NACCO MATERIALS 1661840
NEUSON 1000178670
SCANIA 1879099
TEREX 83169540
VOLVO 11703741
VOLVO VOE11703741
WACKER 1000178670
Parameter
Outlet Diameter: 178 mm (7.01 inch)
Inlet Diameter: 178 mm (7.01 inch)
Body Diameter: Maximum 381 mm (15.00 inch)
Overall Length: 660 mm (25.98 inch)
Body Length: 590 mm (23.23 inch)
Inlet Length: 241.5 mm (9.51 inch)
Outlet Length: 70 mm (2.76 inch)
Service Clearance 540 mm (21.26 inch)
Rated Flow LR: 28 m³/min (989 cfm)
Rated Flow MR: 32 m³/min (1130 cfm)
Rated Flow HR: 36 m³/min (1271 cfm)
Family: ERB
Inlet Location 136 mm (5.35 inch)
Packaged Dimensions
Packaged Length: 51.00 cm (20.08 inch)
Packaged Width: 43.00 cm (16.93 inch)
Packaged Height: 73.00 cm (28.74 inch)
Packaged Weight: 15.00 kg (33.08 lb)
Packaged Volume: 0.16 m3 (5.65 ft3)
