Description
Filter inside:
Standard Version P181039
Long-life Version P182039
Internal filter P114931
Cross Reference
BUHLER VERSATILE 500602
CAMECO 0061327673
CAMECO 61327673
CARQUEST 87128
COMPACTION AMERICA 31008800
EUCLID 2510522
EUCLID M2510522
HENGST E744L
HENGST E744LS
HIFI FILTER SA10833
KOEHRING 31008800
LETOURNEAU 4073728
LETOURNEAU 5755856
MANN C361142
MANN CF22269
RIMPULL 215046
UNIFLUX XA1261
UNIT RIG EQUIPMENT SC015041030
UNIT RIG SC015041030
VERMEER 613663001
WIX 42128
WIX 42132
Parameter
Outlet Diameter: 178 mm (7.01 inch)
Inlet Diameter: 330 mm (12.99 inch)
Body Diameter: Maximum 406 mm (15.98 inch)
Body Length: 500 mm (19.68 inch)
Rated Flow LR: 29.7 m³/min (1049 cfm)
Rated Flow MR: 34.7 m³/min (1225 cfm)
Rated Flow HR: 39.6 m³/min (1398 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Family: STB
Brand: Strata™
Packaged Dimensions
Packaged Length: 90.17 cm (35.50 inch)
Packaged Width: 53.98 cm (21.25 inch)
Packaged Height: 67.95 cm (26.75 inch)
Packaged Weight: 36.86 kg (81.20 lb)
Packaged Volume: 0.33 m3 (11.68 ft3)
