Description
Cross Reference
DONALDSON ECB160265
HIFI FILTER SAB160265
KOHLER 330570181
MTU 0180947102
SF FILTER SL83071
WEICHAI 1001818269
Parameter
Outlet Diameter: 250 mm (9.84 inch)
Body Diameter: Maximum 425 mm (16.73 inch)
Body Length: 430 mm (16.93 inch)
Efficiency 99.60
Efficiency Test Std: ISO 5011
Rated Flow LR: 47 m³/min (1660 cfm)
Rated Flow MR: 77 m³/min (2719 cfm)
Rated Flow HR: 109 m³/min (3849 cfm)
Restriction: LR: 3.92 mbar (1.57 inch H2O)
Restriction: MR: 9.81 mbar (3.94 inch H2O)
Restriction: HR: 19.61 mbar (7.87 inch H2O)
Family: ECB
Type: Primary
Media Type: Cellulose
Packaged Dimensions
Packaged Length: 51.00 cm (20.08 inch)
Packaged Width: 51.00 cm (20.08 inch)
Packaged Height: 51.00 cm (20.08 inch)
Packaged Weight: 7.74 kg (17.07 lb)
Packaged Volume: 0.13 m3 (4.68 ft3)
Pieces Per Pallet 16
Pieces Per Box 1
