Description
Filter inside:
Standard Version P785394
Internal filter P785395
Use With COVER ASSEMBLY P785546
Or filter kit X770688
Cross Reference
DONALDSON ERB180017
HIFI FILTER SAH01C18ADH001
LOESING 22167
SCANIA 1879436
Parameter
Outlet Diameter: 203 mm (7.99 inch)
Inlet Diameter: 254 mm (10.00 inch)
Body Diameter: Maximum 457 mm (17.99 inch)
Overall Length: 735 mm (28.94 inch)
Length: 651 mm (25.63 inch)
Body Length: 650 mm (25.59 inch)
Inlet Length: 328 mm (12.91 inch)
Outlet Length: 85 mm (3.35 inch)
Service Clearance 600 mm (23.62 inch)
Rated Flow LR: 65 m³/min (2295 cfm)
Rated Flow MR: 74 m³/min (2613 cfm)
Rated Flow HR: 83 m³/min (2931 cfm)
Family: ERB
Inlet Location 279 mm (10.98 inch)
Packaged Dimensions
Packaged Length: 84.99 cm (33.46 inch)
Packaged Width: 62.99 cm (24.80 inch)
Packaged Height: 57.99 cm (22.83 inch)
Packaged Weight: 25.00 kg (55.13 lb)
Packaged Volume: 0.31 m3 (10.97 ft3)
