Description
Cross Reference
AIR MAZE SEFC854
AIR REFINER ARM085004
AIR SUPPLY 121808
ASSOCIATE AUTOMOTIVE GP17OP
ATLAS COPCO 1310250345
BALDWIN PA2805
BIG A 94314
BOSS INDUSTRIES 305639
CARQUEST 88314
CASE/CASE IH NX14210064
CATERPILLAR 3I0017
CHAMPION LAF1833
CHARDONNET 7308500400
CHARLES MACHINE 153495
CHARLES MACHINE 153495A
CHARLES MACHINE WORKS 153495
CHARLES MACHINE WORKS 153495A
CLARK 110332145
COMPAIR 438672
CUMMINS 3908719
DEUTZ 305283
DITCH WITCH 153495A
DMT CORPORATION 100554
DONSSON DA7801
EUCLID 11033214
FIAT 8007965
FLEETRITE AHR81107
FORD 9576C085004
FREIGHTLINER DNC085004
GREYFRIARS 1510A
HANOMAG TRAKTOREN 42506H4190
HASTINGS AF2033
HASTINGS PA2805
HAVAM HD1882
HENGST E1494L
HIFI FILTER SAC085004
HIMOINSA 3031797
ISUZU X14210048
IVECO 8007965
JOHN DEERE RE504073
JURA SAC085004
KELTEC KC205019
KRALINATOR LA1436
KUKJE YGT00135
LECHMOTOREN 105020046
LEROI 438672
LISTER PETTER 00003044
LISTER PETTER 3044
LOESING 021789
LOESING 21789
M.D.F. SARL MDA3381
MACO MEUDON COMPRESSORS 529849
NATO (NSN) 2940013321662
OSHKOSH 2HB912
RAINBOW MANUFACTURING 15627
RENAULT VI 5000674688
SDMO 30801011203
SULLAIR 529849
SULLAIR 68529849
TAYLOR VTECC085004
VMC AH85004
VME 11033214
VOLVO 11033214
VOLVO VOE11033214
WALGAHN MOTORENTECHN 00810055
WALGAHN MOTORENTECHN 810055
WIX 46314
WORTHINGTON 104595
Parameter
Outlet Diameter: 76.2 mm (3.00 inch)
Body Diameter: Maximum 215.9 mm (8.50 inch)
Body Length: 241.3 mm (9.50 inch)
Efficiency Test Std: ISO 5011
Rated Flow LR: 4.8 m³/min (170 cfm)
Rated Flow MR: 5.8 m³/min (205 cfm)
Rated Flow HR: 6.9 m³/min (244 cfm)
Restriction: LR: 10 mbar (4.02 inch H2O)
Restriction: MR: 14.91 mbar (5.98 inch H2O)
Restriction: HR: 19.91 mbar (7.99 inch H2O)
Family: ECC
Type: Primary
Style: Round
Brand: DuraLite™
Media Type: Cellulose
Packaged Dimensions
Packaged Length: 21.79 cm (8.58 inch)
Packaged Width: 21.79 cm (8.58 inch)
Packaged Height: 29.72 cm (11.70 inch)
Packaged Weight: 1.33 kg (2.93 lb)
Packaged Volume: 0.02 m3 (0.58 ft3)
