Description
Filter inside:
External filter P617631
Internal filter P615493
Cross Reference
HIFI FILTER SAH01D09AEP001
Parameter
Outlet Diameter: 88.7 mm (3.49 inch)
Overall Length: 369.5 mm (14.55 inch)
Body Length: 166.5 mm (6.56 inch)
Rated Flow LR: 5.4 m³/min (191 cfm)
Rated Flow MR: 6.3 m³/min (222 cfm)
Rated Flow HR: 7.1 m³/min (251 cfm)
Restriction: LR: 14.95 mbar (6 inch H2O)
Restriction: MR: 19.93 mbar (8 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Family: PSD
Media Brand: PowerCore®
Packaged Dimensions
Packaged Length: 29.46 cm (11.60 inch)
Packaged Width: 30.48 cm (12.00 inch)
Packaged Height: 44.20 cm (17.40 inch)
Packaged Weight: 2.74 kg (6.05 lb)
Packaged Volume: 0.04 m3 (1.40 ft3)
