Description
Filter inside:
Standard version P957050
Blue version DBA9333
Cross Reference
DONALDSON D100030
SANDVIK 64598722
Parameter
Outlet Diameter: 127 mm (5 inch)
Overall Length: 429 mm (16.89 inch)
Notes Access Cover and outlet tube are positioned 180DEG compared to the Access cover and outlet tube locations on the D100398
Body Length: 198.9 mm (7.83 inch)
Rated Flow LR: 14.5 m³/min (512 cfm)
Rated Flow MR: 16.9 m³/min (597 cfm)
Rated Flow HR: 19 m³/min (671 cfm)
Restriction: LR: 14.95 mbar (6 inch H2O)
Restriction: MR: 19.93 mbar (8 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Family: PSD
Media Brand: PowerCore®
Packaged Dimensions
Packaged Length: 49.99 cm (19.68 inch)
Packaged Width: 35.99 cm (14.17 inch)
Packaged Height: 40.01 cm (15.75 inch)
Packaged Weight: 5.50 kg (12.13 lb)
Packaged Volume: 0.07 m3 (2.54 ft3)
