Description
Filter inside:
External filter P600043
Internal filter P600047
Parameter
Outlet Diameter: 63.5 mm (2.50 inch)
Inlet Diameter: 63.5 mm (2.50 inch)
Body Diameter: Maximum 133.35 mm (5.25 inch)
Overall Length: 433.3 mm (17.06 inch)
Body Length: 293.7 mm (11.56 inch)
Rated Flow LR: 2.3 m³/min (81 cfm)
Rated Flow MR: 2.7 m³/min (95 cfm)
Rated Flow HR: 3 m³/min (106 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Style: Radialseal
Family: FRG
Brand: RadialSeal™
Packaged Dimensions
Packaged Length: 52.07 cm (20.50 inch)
Packaged Width: 31.24 cm (12.30 inch)
Packaged Height: 40.13 cm (15.80 inch)
Packaged Weight: 3.41 kg (7.52 lb)
Packaged Volume: 0.06 m3 (2.31 ft3)
