Description
Filter inside:
External filter P780522
Internal filter P780523
Or air filter kit X012152 (P780523+P780522)
Cross Reference
AMERICAN AUGERS 8NG1001803
AMMANN 1495173
ASTEC UNDERGROUND 8NG1001803
ATLAS COPCO 1310035497
ATLAS WEYHAUSEN 7502594
AUSA CKC01B17
CASE/CASE IH 85821057
CASE/CASE IH 920019202
CUMMINS 10001017
DEUTZ FAHR 140670420
DIAMANT BOART INC 574531701
DITCH WITCH 194121
ELGIN 1074511
FIAT 76088513
HIFI FILTER SAH01C09AMP001
JCB 32925398
JLG 10268515
KAESSBOHRER 83191890000
LAVERDA 4302415000
LIEBHERR 7415472
M.Z. IMER M007281
MACDON 112476
MECALAC 6050142
MERLO 49501
MERLO 63234
NEW HOLLAND 920019202
NEW HOLLAND FF3043130
ORENSTEIN & KOPPEL 29288398839
SAME 1406704
SAME 242497170
SUNWARD 750201011551
TORO 1127329
VERMEER 155957001
VOLVO A601100
VOLVO CONSTRUCTION EQUIPMENT 15605446
VOLVO CONSTRUCTION EQUIPMENT X003285
WORDSWORTH HOLDINGS PLC SX621171
YTO 240100013925
Parameter
Outlet Diameter: 89 mm (3.50 inch)
Inlet Diameter: 114 mm (4.49 inch)
Body Diameter: Maximum 242 mm (9.53 inch)
Overall Length: 453.5 mm (17.85 inch)
Body Length: 322.6 mm (12.70 inch)
Rated Flow LR: 7.2 m³/min (254 cfm)
Rated Flow MR: 9 m³/min (318 cfm)
Rated Flow HR: 9.8 m³/min (346 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Style: Radialseal
Family: FPG
Brand: RadialSeal/Alexin™
Packaged Dimensions
Packaged Length: 50.29 cm (19.80 inch)
Packaged Width: 29.97 cm (11.80 inch)
Packaged Height: 56.13 cm (22.10 inch)
Packaged Weight: 4.00 kg (8.82 lb)
Packaged Volume: 0.08 m3 (2.99 ft3)
