Description
Filter inside:
External filter P781039
Internal filter P777639
Cross Reference
AG CHEM EQUIPMENT 121510
AG CHEM EQUIPMENT 121520
AGCO WR121510
CASE/CASE IH BN68873
CUMMINS 10000524
DENYO Y0602046258
DYNAPAC 393088U
EIMCO 88537939
ELGIN 1072963
GRADALL 80373056
GROVE 7304100007
GROVE 7304100010
HIFI FILTER SAH01C10ADH003
HOIST LIFTTRUCK MANUFACTURING II00004
JLG 1001091068
JLG 80373056
JOHN DEERE AT203471
JOHN DEERE T203471
MANITOWOC 7304100010
MARINE TRAVELIFT, INC. 1009867
MI JACK 43160001
MORBARK 29320611
PERKINS 13000223
RED DOT RD593000
SAKAI 4421600000
SUPERPAK COMPACTION 210484
TIMBERJACK AT203471
TYLER POWER PRODUCTS 68873
TYLER POWER PRODUCTS BN68873
Parameter
Outlet Diameter: 104.2 mm (4.10 inch)
Inlet Diameter: 114.3 mm (4.50 inch)
Body Diameter: Maximum 258.8 mm (10.19 inch)
Overall Length: 495.7 mm (19.52 inch)
Body Length: 358.5 mm (14.11 inch)
Rated Flow LR: 7.6 m³/min (268 cfm)
Rated Flow MR: 8.6 m³/min (304 cfm)
Rated Flow HR: 9.6 m³/min (339 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Style: Radialseal
Family: FRG
Brand: RadialSeal™
Packaged Dimensions
Packaged Length: 49.28 cm (19.40 inch)
Packaged Width: 29.72 cm (11.70 inch)
Packaged Height: 50.55 cm (19.90 inch)
Packaged Weight: 7.23 kg (15.92 lb)
Packaged Volume: 0.07 m3 (2.61 ft3)
