Description
Filter inside:
External filter P781039
Internal filter P777639
Cross Reference
AGCO 948272M91
AGCO N1009010H
ASPLUNDH G100036
ATLAS COPCO 344826
ATLAS WEYHAUSEN 0463178
BAUER N08566
CASE/CASE IH 1849261
CASE/CASE IH R36360
CASE/CASE IH R48001
CHAMPION ROAD 205985
CHARDONNET 7310002933
CHARDONNET 7310003633
CLAAS 7700058783
DEUTZ 4146772
DEUTZ 948272M91
DOMINION 3154698R91
DRESSER 3154698R91
DYNAPAC 4700802146
DYNAPAC 802146
DYNAPAC 802147
EIMCO 0701066
EIMCO 3546001
EIMCO 64400575
EIMCO 701066
FAUN 4134340
FIAT 1849261
FLEETGUARD AF434KM
FLEETGUARD AF804M
FMC 2262134
FURUKAWA 3154698R91
GETMAN 604116
GRADALL 83671048
GROVE 7304000093
HAMM 2044798
HAVAM HD2450
HAVAM HD2470
HITACHI 3154698R91
INGERSOLL RAND N08566
IVECO 737493
KNECHT LX1579
KOEHRING 21000033
KOEHRING 8273016
KOMATSU 79454
LIEBHERR 5802097
LOCATELLI 4430113
LOESING 020058
LOESING 20056
LOESING 20058
LULL 10866107
LULL 66107X
MAGNETI MARELLI 154766436700
MAHLE LX1579
MASSEY FERGUSON 948272M91
MCCORMICK R36360
NEUSON 1000066891
NEW HOLLAND 1849261
OSHKOSH 28063A
OTTAWA TRUCK 9209690034
PERKINS A100319
RENAULT VI 737493
ROTORCOMP N08566
SOLMEC SPA 2102106058
TAMROCK 64400575
VM MOTORI 311130002A
VM MOTORI 31130002A
WAGNER MINING EQUIPMENT 344826
WALGAHN MOTORENTECHN 00810116
WALGAHN MOTORENTECHN 810114
Parameter
Outlet Diameter: 101.5 mm (4.00 inch)
Inlet Diameter: 114 mm (4.49 inch)
Body Diameter: Maximum 268 mm (10.55 inch)
Overall Length: 515.6 mm (20.30 inch)
Body Length: 350.5 mm (13.80 inch)
Rated Flow LR: 7.3 m³/min (258 cfm)
Rated Flow MR: 8.4 m³/min (297 cfm)
Rated Flow HR: 9.3 m³/min (328 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Style: Radialseal
Family: FPG
Brand: SCA+™
Packaged Dimensions
Packaged Length: 46.00 cm (18.11 inch)
Packaged Width: 30.00 cm (11.81 inch)
Packaged Height: 62.00 cm (24.41 inch)
Packaged Weight: 4.54 kg (10.01 lb)
Packaged Volume: 0.08 m3 (3.02 ft3)
