Description
Filter inside:
External filter P772531
Internal filter P770678
Cross Reference
CAB’S INDUSTRIES 9PU180
EXMAN 6211457500
LEYLAND BCU1748
MOUVEX 215651
SOILMEC 40040006
TEREX 0906040669
TEREX 906040669
WALGAHN MOTORENTECHN 00810133
WALGAHN MOTORENTECHN 810133
Parameter
Outlet Diameter: 127 mm (5.00 inch)
Inlet Diameter: 127 mm (5.00 inch)
Body Diameter: Maximum 300 mm (11.81 inch)
Overall Length: 496 mm (19.53 inch)
Body Length: 405 mm (15.94 inch)
Rated Flow LR: 9 m³/min (318 cfm)
Rated Flow MR: 13 m³/min (459 cfm)
Rated Flow HR: 16 m³/min (565 cfm)
Restriction: LR: 9.81 mbar (3.94 inch H2O)
Restriction: MR: 19.61 mbar (7.87 inch H2O)
Family: FLG
Packaged Dimensions
Packaged Length: 51.00 cm (20.08 inch)
Packaged Width: 38.99 cm (15.35 inch)
Packaged Height: 40.01 cm (15.75 inch)
Packaged Weight: 10.47 kg (23.09 lb)
Packaged Volume: 0.08 m3 (2.81 ft3)
