Description
Filter inside:
External filter P181044，P182044
Internal filter P119371
Cross Reference
CASE/CASE IH A075060
CASE/CASE IH P0850553
CASE/CASE IH P850553
CATERPILLAR 1X8139
CHAMPION ROAD 15914
DRILTECH 4710001
EIMCO 04710001
HAVAM HD9790
HIFI FILTER SAH01B12ADM007
LEROI GD1415937
MI JACK 37216704SUB
NEW HOLLAND P0850553
SANDVIK 04710001
TAMROCK 04710001
TEREX 9018191
TEREX P0850553
WALGAHN MOTORENTECHN 00810128
WALGAHN MOTORENTECHN 810128
Parameter
Outlet Diameter: 127 mm (5.00 inch)
Inlet Diameter: 127 mm (5.00 inch)
Body Diameter: Maximum 299.97 mm (11.81 inch)
Width: 375 mm (14.76 inch)
Body Length: 392 mm (15.43 inch)
Rated Flow LR: 11 m³/min (388 cfm)
Rated Flow MR: 12.9 m³/min (456 cfm)
Rated Flow HR: 14.6 m³/min (516 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Style: Tubular
Family: STG
Brand: Donaclone™
Packaged Dimensions
Packaged Length: 90.81 cm (35.75 inch)
Packaged Width: 53.98 cm (21.25 inch)
Packaged Height: 58.42 cm (23.00 inch)
Packaged Weight: 26.60 kg (58.60 lb)
Packaged Volume: 0.28 m3 (10.11 ft3)
