Description
Filter inside:
External filter P601767
Internal filter P601774
Cross Reference
ATLAS WEYHAUSEN 869054
BLOUNT 10082116
CATERPILLAR 10082116
CUMMINS 10000631
CUMMINS 30342427
DONALDSON G120014 / G120036
FAUN 746756
LOESING 20060
PETTIBONE LL847457
WALGAHN MOTORENTECHN 810125
WALGAHN MOTORENTECHN 810126
WHITE 302008408
Parameter
Outlet Diameter: 127 mm (5.00 inch)
Inlet Diameter: 127 mm (5.00 inch)
Body Diameter: Maximum 300 mm (11.81 inch)
Overall Length: 541.9 mm (21.33 inch)
Body Length: 484 mm (19.06 inch)
Rated Flow LR: 8.9 m³/min (314 cfm)
Rated Flow MR: 9.9 m³/min (350 cfm)
Rated Flow HR: 11.8 m³/min (417 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Style: Radialseal
Family: FRG
Brand: RadialSeal™
Packaged Dimensions
Packaged Length: 42.93 cm (16.90 inch)
Packaged Width: 65.53 cm (25.80 inch)
Packaged Height: 51.05 cm (20.10 inch)
Packaged Weight: 13.96 kg (30.75 lb)
Packaged Volume: 0.14 m3 (5.07 ft3)
