Description
Filter inside:
External filter P601767
Internal filter P601774
Cross Reference
BRODERSON 060012205
BRODERSON 60012205
CASE/CASE IH N101953
DEUTZ E0304466
DITCH WITCH 194599
DITCH WITCH O0023725A
Parameter
Outlet Diameter: 127 mm (5.00 inch)
Inlet Diameter: 127 mm (5.00 inch)
Body Diameter: Maximum 300 mm (11.81 inch)
Overall Length: 541.9 mm (21.33 inch)
Body Length: 484 mm (19.06 inch)
Rated Flow LR: 11.6 m³/min (410 cfm)
Rated Flow MR: 13 m³/min (459 cfm)
Rated Flow HR: 14.9 m³/min (526 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Style: Radialseal
Family: FRG
Brand: RadialSeal™
Packaged Dimensions
Packaged Length: 60.45 cm (23.80 inch)
Packaged Width: 35.31 cm (13.90 inch)
Packaged Height: 49.78 cm (19.60 inch)
Packaged Weight: 12.92 kg (28.47 lb)
Packaged Volume: 0.11 m3 (3.75 ft3)
