Description
Filter inside:
External filter P777409
Internal filter P777414
Cross Reference
AGCO 3780822M1
CATERPILLAR 481238
CUMMINS CDD000005
DEZZI 350046
DONALDSON FRG130061
DYNAPAC 385171
EIMCO 88538009
EUCLID 11033953
FIAT 76066325
FIAT 76092392
FURUKAWA 38802111200
HANOMAG TRAKTOREN 42401H2130
HIFI FILTER SAH01C13ADH003
HYSTER T1506806
JOHN DEERE AT175200
JOHN DEERE AT175200A
KALMAR 9209690023
KALMAR R1004096H
LOESING 021685
MAN 56084016507
SANDVIK 55084695
TAMROCK 04710339
TAMROCK 4710339
TAMROCK 671726
TAMROCK 88538009
TAMROCK A88538009
VME 11033953
VOLVO 11033953
Parameter
Outlet Diameter: 127 mm (5.00 inch)
Inlet Diameter: 152.5 mm (6.00 inch)
Body Diameter: Maximum 330 mm (12.99 inch)
Overall Length: 588 mm (23.15 inch)
Length: 530 mm (20.87 inch)
Body Length: 446.5 mm (17.58 inch)
Inlet Length: 216 mm (8.50 inch)
Outlet Length: 58 mm (2.28 inch)
Service Clearance 470 mm (18.50 inch)
Style: Radialseal
Family: FRG
Brand: RadialSeal™
Vacuator Clearance 301 mm (11.85 inch)
Inlet Location 132 mm (5.20 inch)
Packaged Dimensions
Packaged Length: 51.99 cm (20.47 inch)
Packaged Width: 43.00 cm (16.93 inch)
Packaged Height: 73.00 cm (28.74 inch)
Packaged Weight: 12.03 kg (26.53 lb)
Packaged Volume: 0.16 m3 (5.76 ft3)
