Description
Filter inside:
Blue Version External filter DBA5220
Standard version External filter P532503
Internal filter P532504
Standard version filter kit R000706= P532503+P532504
Cross Reference
AGCO 700727338
CATERPILLAR 10068511
CUMMINS 10000647
DITCH WITCH 194672
DITCH WITCH 194672A
HAY & FORAGE 700727338
LINK BELT D7A0735
PETTIBONE LL847499
REEDRILL 435288
Parameter
Outlet Diameter: 127 mm (5.00 inch)
Inlet Diameter: 152.4 mm (6.00 inch)
Body Diameter: Maximum 329.7 mm (12.98 inch)
Overall Length: 491.8 mm (19.36 inch)
Body Length: 341 mm (13.43 inch)
Rated Flow LR: 12.5 m³/min (441 cfm)
Rated Flow MR: 14.4 m³/min (509 cfm)
Rated Flow HR: 16.1 m³/min (569 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Style: Radialseal
Family: FRG
Brand: RadialSeal™
Packaged Dimensions
Packaged Length: 52.83 cm (20.80 inch)
Packaged Width: 35.81 cm (14.10 inch)
Packaged Height: 50.80 cm (20.00 inch)
Packaged Weight: 10.05 kg (22.14 lb)
Packaged Volume: 0.10 m3 (3.39 ft3)
