Description
Filter inside:
External filter P785590
Internal filter P785401
Filter kit X770693=P785590+P785401
Cross Reference
AGCO AG122214
ATLAS 1615804900
ATLAS 1615804901
ATLAS COPCO 1606736101
ATLAS COPCO 3222188150
BMC 52RS017297
BMC 52RS0179297
BMC 53RS201068
BMC 54RS250786
BREDAMENARINIBUS D048530A
CASE/CASE IH 76049605
CASE/CASE IH P6150581
CATERPILLAR 1420329
CLAAS 142446
CLAAS 1424460
COMPAIR A13368474
CUMMINS CDD000120
DONALDSON FRG150255
FG WILSON 160261
FIAT 76049605
FRESIA 95127
FURUKAWA 38902111200
GINAF OG0000017166
HITACHI 38902111200
HITACHI 76049605
IMPERIAL CV102728
IVECO 97166007
IVECO G150092930610
JCB 332T0097
JOHN DEERE F121903
KALMAR 9209690024
KRONE 9386600
LOESING 20667
MI JACK G150092
MOXY 351855
NEW HOLLAND 2426659
NEW HOLLAND 76049605
NEW HOLLAND P6150581
RAMA MOTORI JFRG150255
SANDVIK 4710009
SANDVIK 471000955009422
SANDVIK 502852
SANDVIK 55009422
SDMO 30801020501
SEDDON ATKINSON 97166007
TAMROCK 2950418
TAMROCK 4710009
TAMROCK 471000955009422
TAMROCK 502852
TAMROCK 55009422
TEREX 15254860
TEREX P6150581
TOIJALA WORKS K1001086H
TYLER POWER PRODUCTS 87733701
Parameter
Outlet Diameter: 152 mm (5.98 inch)
Inlet Diameter: 178 mm (7.01 inch)
Body Diameter: Maximum 381 mm (15.00 inch)
Overall Length: 600 mm (23.62 inch)
Length: 530 mm (20.87 inch)
Body Length: 446.5 mm (17.58 inch)
Inlet Length: 241.5 mm (9.51 inch)
Outlet Length: 70 mm (2.76 inch)
Service Clearance 483 mm (19.02 inch)
Rated Flow LR: 20.3 m³/min (717 cfm)
Rated Flow MR: 22.8 m³/min (805 cfm)
Rated Flow HR: 26.8 m³/min (946 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Style: Radialseal
Family: FRG
Brand: RadialSeal™
Vacuator Clearance 338 mm (13.31 inch)
Inlet Location 140.1 mm (5.52 inch)
Packaged Dimensions
Packaged Length: 50.52 cm (19.89 inch)
Packaged Width: 46.56 cm (18.33 inch)
Packaged Height: 62.41 cm (24.57 inch)
Packaged Weight: 13.97 kg (30.80 lb)
Packaged Volume: 0.16 m3 (5.73 ft3)
