Description
Filter inside:
External filter P181042，P182042
Internal filter P128408
Cross Reference
ALLIED SYSTEM 226636
ASTEC UNDERGROUND 3018051282
BEST ENGINEERING P05297
CMI P1023185101
CMI P1073185101
EIMCO 64133050
ENMTP CPG 5606336
LIEBHERR 5606336
LONG G161020
SANDVIK 64133050
SIGMA AIR CONDITIONING 460C028
Parameter
Outlet Diameter: 203.2 mm (8.00 inch)
Inlet Diameter: 152 mm (5.98 inch)
Body Diameter: Maximum 406 mm (15.98 inch)
Overall Length: 750.824 mm (29.56 inch)
Width: 457 mm (17.99 inch)
Body Length: 609.7 mm (24.00 inch)
Rated Flow LR: 40 m³/min (1413 cfm)
Rated Flow MR: 37 m³/min (1307 cfm)
Rated Flow HR: 41.5 m³/min (1466 cfm)
Restriction: LR: 14.91 mbar (5.98 inch H2O)
Restriction: MR: 19.91 mbar (7.99 inch H2O)
Restriction: HR: 24.91 mbar (10 inch H2O)
Style: Tubular
Family: STG
Brand: Donaclone™
Packaged Dimensions
Packaged Length: 93.98 cm (37.00 inch)
Packaged Width: 80.65 cm (31.75 inch)
Packaged Height: 46.36 cm (18.25 inch)
Packaged Weight: 45.40 kg (100.00 lb)
Packaged Volume: 0.35 m3 (12.41 ft3)
