Description
Filter inside:
External filter P781098
Internal filter P781102
Filter kit X011398=P781098+P781102
Parameter
Outlet Diameter: 203 mm (7.99 inch)
Inlet Diameter: 203 mm (7.99 inch)
Body Diameter: Maximum 457 mm (17.99 inch)
Body Length: 650 mm (25.59 inch)
Rated Flow LR: 26 m³/min (918 cfm)
Rated Flow MR: 34 m³/min (1201 cfm)
Rated Flow HR: 42 m³/min (1483 cfm)
Restriction: LR: 9.81 mbar (3.94 inch H2O)
Restriction: MR: 19.61 mbar (7.87 inch H2O)
Restriction: HR: 29.42 mbar (11.81 inch H2O)
Style: Radialseal
Family: FRG
Packaged Dimensions
Packaged Length: 78.99 cm (31.10 inch)
Packaged Width: 59.99 cm (23.62 inch)
Packaged Height: 73.00 cm (28.74 inch)
Packaged Weight: 22.00 kg (48.51 lb)
Packaged Volume: 0.34 m3 (12.22 ft3)
