Description
Filter inside:
External filter P786197
Internal filter P786198
Cross Reference
ATLAS COPCO 3222308484
CLAAS 1421650
CUMMINS CDD000970
DONALDSON FRG180087
HIFI FILTER SAH01C18ADH003
KALMAR 920969003
KRONE 9403060
NEUSON 1000194264
UP LIFTING VERTICAL S.A. 5490091006
WACKER 1000194264
Parameter
Outlet Diameter: 178 mm (7.01 inch)
Inlet Diameter: 203 mm (7.99 inch)
Body Diameter: Maximum 457 mm (17.99 inch)
Overall Length: 595 mm (23.43 inch)
Body Length: 423 mm (16.65 inch)
Rated Flow LR: 23 m³/min (812 cfm)
Rated Flow MR: 30.2 m³/min (1067 cfm)
Rated Flow HR: 37 m³/min (1307 cfm)
Restriction: LR: 9.81 mbar (3.94 inch H2O)
Restriction: MR: 19.61 mbar (7.87 inch H2O)
Restriction: HR: 29.42 mbar (11.81 inch H2O)
Style: Radialseal
Family: FRG
Brand: RadialSeal™
Packaged Dimensions
Packaged Length: 83.19 cm (32.75 inch)
Packaged Width: 61.60 cm (24.25 inch)
Packaged Height: 57.15 cm (22.50 inch)
Packaged Weight: 22.68 kg (50.01 lb)
Packaged Volume: 0.29 m3 (10.34 ft3)
