Description
CUP：P016330
Parameter
Height: 195 mm (7.68 inch)
Body Diameter: Maximum 269.75 mm (10.62 inch)
Outlet ID 115.32 mm (4.54 inch)
Efficiency 75
Efficiency Test Std: ISO 5011, SAE J726
Rated Flow HR: 9.6 m³/min (339 cfm)
Restriction: LR: 2.45 mbar (0.98 inch H2O)
Restriction: HR: 7.45 mbar (2.99 inch H2O)
Packaged Dimensions
Packaged Length: 27.99 cm (11.02 inch)
Packaged Width: 27.99 cm (11.02 inch)
Packaged Height: 26.01 cm (10.24 inch)
Packaged Weight: 1.69 kg (3.72 lb)
Packaged Volume: 0.02 m3 (0.72 ft3)
