Description
Cross Reference
A P PARTS 3626
A P PARTS 3626Q
AP EXHAUST PRODUCTS INC 3626
ASTEC UNDERGROUND 304605097
B R LEE INDUSTRIES 36790
BADGER 76080439
BARKO HYDRAULICS 53501016
BRODERSON 060094217
BRODERSON 60094217
CAMECO 0550038023
CAMECO 05538023
CAMECO 550038023
CAMECO 5538023
CATERPILLAR 0980240
CATERPILLAR 980240
CETCO INCORPORATED 1243327H1
CHAMPION ROAD 205996
CHARDONNET 7408509000
CMI 400298000
CMI 4002980000
CMI 413224
DRESSER 1243327H1
DYNAFLEX 88H300102
DYNAFLEX 88H300192
FORD 9575M085090
FREIGHTLINER DNM085090
GENERAC 0D8473
GENERAC OD8473
GENERAC OD8473R
GRADALL 1755012
GROVE 7642000029
HAVAM 00008223
HAVAM 8223
HEAVY DUTY MFG 31102
INGERSOLL RAND 22320253
INGERSOLL RAND 35576271
INGERSOLL RAND 50901719
INGERSOLL RAND 59189100
INTERNATIONAL DCM085090
ISUZU X14152005
KOEHRING 125695
KOHLER 253237
KOMATSU 1243327H1
LEROI 78318
LEROI 783181
LEROI GD1755012
MORBARK 29323072
NELSON 86192M
OSHKOSH 3HS880
OSHKOSH P109398
P & H 27Q686
PANDROL JACKSON 2511251
PETTIBONE 0RO23180076
PETTIBONE 44045
PETTIBONE 53501016
PETTIBONE R02318076
RAYGO 0980240
RAYGO 1207032
RAYGO 1207032A
RAYGO 980240
ROSCO 36790
SELLICK EQPT LTD 190699
STEMCO 1901332
TAYLOR 1007537
VERMEER 116370001
VERMEER 1163700011
WALDON 414714
WALGAHN MOTORENTECHN 00810300
WALGAHN MOTORENTECHN 810300
WALKER MANUFACTURING 22767
Parameter
Flow Direction Inlet-Outlet
Inlet Diameter: 76.66 mm (3.02 inch)
Outlet Diameter: 76.6 mm (3.02 inch)
Body Diameter: Maximum 215 mm (8.46 inch)
Body Length: 666.8 mm (26.25 inch)
Overall Length: 749.3 mm (29.50 inch)
Rated Flow LR: 13.2 m³/min (466 cfm)
Rated Flow MR: 18.6 m³/min (657 cfm)
Rated Flow HR: 22.7 m³/min (802 cfm)
Back Pressure Low-Range 25 mm Hg (0.98 inch Hg)
Back Pressure Mid-Range 51 mm Hg (2.01 inch Hg)
Back Pressure High-Range 76 mm Hg (2.99 inch Hg)
Attenuation LR: 15 dBA
Attenuation HR: 20 dBA
Inlet Clock Position 3:00
Outlet Clock Position 6:00
Style: Style: 3
Packaged Dimensions
Packaged Length: 78.74 cm (31.00 inch)
Packaged Width: 29.85 cm (11.75 inch)
Packaged Height: 22.23 cm (8.75 inch)
Packaged Weight: 9.35 kg (20.60 lb)
Packaged Volume: 0.05 m3 (1.84 ft3)
