Description
Cross Reference
AMERICAN AUGERS 8EG1000403
NELSON 201570N
RAINBOW MANUFACTURING 18416
VERMEER 163642854
Parameter
Flow Direction Inlet-Outlet
Inlet Diameter: 102.11 mm (4.02 inch)
Outlet Diameter: 102.11 mm (4.02 inch)
Body Diameter: Maximum 256 mm (10.08 inch)
Body Length: 603.2 mm (23.75 inch)
Overall Length: 812.8 mm (32.00 inch)
Rated Flow LR: 32 m³/min (1130 cfm)
Rated Flow MR: 44.4 m³/min (1568 cfm)
Rated Flow HR: 56.6 m³/min (1999 cfm)
Back Pressure Low-Range 25 mm Hg (0.98 inch Hg)
Back Pressure Mid-Range 51 mm Hg (2.01 inch Hg)
Back Pressure High-Range 76 mm Hg (2.99 inch Hg)
Attenuation LR: 12 dBA
Attenuation HR: 18 dBA
Style: Style: 1
Packaged Dimensions
Packaged Length: 87.95 cm (34.63 inch)
Packaged Width: 26.67 cm (10.50 inch)
Packaged Height: 26.67 cm (10.50 inch)
Packaged Weight: 9.32 kg (20.53 lb)
Packaged Volume: 0.06 m3 (2.21 ft3)
