Description
Cross Reference
AC DELCO PF2176
AGCO 4232923M1
AMERICAN CRANE CORPORATION 1174455
AMERICAN HOIST 1050495
AMERICAN PARTS 92447
AMERICAN PARTS 92451
ARDCO ENE0181
ATLAS COPCO 372192
BADGER LG77561
BALDWIN BT747
BALDWIN BT8840 MPG
BALDWIN BT8846
BARBER GREENE 8T7478
BIG A 92447
BIG A 92451
BLOUNT F023753
BOMBARDIER 118302300
BOMBARDIER 921183023
BUHLER VERSATILE 500602
CARQUEST 85447
CARQUEST 85451
CASE A165029
CASE IH 1272051X1
CASE IH 92451
CASE IH A165029
CASE/CASE IH 1272051X1
CASE/CASE IH 92451
CASE/CASE IH A165029
CASE/CASE IH D122562
CATERPILLAR 3I0550
CATERPILLAR 3I0567
CATERPILLAR 8C3045
CHAMPION 1612579
CLAAS 5784640
CLARK 759902
CLARK 921796
CLARK M759902
CLARK,J.L. 759902
CLARK,J.L. M759902
CLEAN DH5804
CMI 002008500002
CMI 2008500002
CMI 285002
CMI P163542
CMI P2980653368
COMPACTION AMERICA 0937756
COMPACTION AMERICA 1338200
DITCH WITCH 9700810
DONALDSON P763759
DRIL TECH 73831130
DRILTECH 73831130
DYNAPAC 00081339
FAIREY ARLON CG465
FIL FILTER ZP3170MG
FLEETGUARD HF6562
FLEETGUARD HF6572
FLEETRITE HFR86562
FLEETRITE HFR86572
FORD 9576P163542
FRAM P6873
FRAM P6877
GREY FRIARS HS7675
GREYFRIARS HS7675
GROVE 4270670
GROVE A104120
HASTINGS HF717
HASTINGS HF825
HAVAM HD8810
HENGST H20WD01
HIFI FILTER SH66542
INGERSOLL RAND 59877779
INTRUPA IF7004
INTRUPA IF7004Q
JOHN DEERE F023753
JURA SH66542
KELTEC KL670013
KOMATSU 20R60R1251
KRALINATOR L451
LIUGONG 53C0375
LOESING 020815
LOESING 20815
LUBER FINER LFH4471
M.D.F. SARL MDH6033
MANITOWOC 4270670
MANN & HUMMEL WH945/1
MANN & HUMMEL WH9451
MANN WH945/1
MANN WH9451
MARINE TRAVELIFT 1906209
MARINE TRAVELIFT, INC. 1906209
MDF SARL MDH6033
MORBARK 26746148
NAPA 1447
NAPA 1451
POWER BOSS 20531
POWER BOSS 300359
POWER BOSS 3300359
PRINOTH 118302300
PUROLATOR H35028
RAYGO 8C3045
RAYGO 8T7478
SANDVIK SC73831130
SAUER DANFOSS INC V544379
SAUER SUNDSTRAND 503933
SAUER SUNDSTRAND 544379
SAUER SUNDSTRAND 9700810
SAUER SUNDSTRAND V544379
TAMPO 81339
TAMROCK 73831130
TIMBERJACK F023753
TORO 013170210
TORO 13170210
VALMET 5006793
VAPORMATIC VPJ4515
VERMEER 67581001
VERMEER 9700810
VMC HF163542
WAGNER MINING 372192
WAGNER MINING EQUIPMENT 372192
WALGAHN MOTOREN 00810952
WALGAHN MOTORENTECHN 00810952
WALGAHN MOTORENTECHN 810952
WESTERN EM352B1R20
WIX 451
WIX 51447
WIX 51451
WOODGATE WGH6572
ZINGA XME10
Parameter
Outer Diameter: 97 mm (3.82 inch)
THR:ead Size: 1 3/8-12 UN
Length: 151.7 mm (5.97 inch)
Gasket OD 70 mm (2.76 inch)
Gasket ID 63 mm (2.48 inch)
Efficiency Beta 2 4 micron
Efficiency Beta 1000 11 micron
Efficiency Test Std: ISO 16889
Collapse Burst 34.5 bar (500 psi)
Flow Direction Standard
Style: Spin-On
Series HMK04/24
Brand: Duramax®
Media Type: Synteq XP
Primary Application CASE/CASE IH A165029
Packaged Dimensions
Packaged Length: 10.16 cm (4.00 inch)
Packaged Width: 10.16 cm (4.00 inch)
Packaged Height: 16.51 cm (6.50 inch)
Packaged Weight: 0.97 kg (2.14 lb)
Packaged Volume: 0.00 m3 (0.06 ft3)
