Description
Cross Reference
BALDWIN OB8731
BOMBARDIER 118302400
PRINOTH 118302400
THOMAS 035244
THOMAS 35244
Parameter
Length: 103.63 mm (4.08 inch)
Height: 85.85 mm (3.38 inch)
Inlet Size: 1-11 1/2 NPT
Outlet Size: 1-11 1/2 NPT
Filter-to-Head THR:ead 1 3/8-12 UN
Bypass Valve Yes
Bypass Valve Setting LR: 1.7 bar (25 psi)
Series HMK04/24
Brand: Duramax®
Packaged Dimensions
Packaged Length: 12.19 cm (4.80 inch)
Packaged Width: 12.19 cm (4.80 inch)
Packaged Height: 14.22 cm (5.60 inch)
Packaged Weight: 0.66 kg (1.45 lb)
Packaged Volume: 0.00 m3 (0.07 ft3)
