Description
Cross Reference
ALCOA MARINE HO823
AMERICAN MOTORS CORPORATION HO823
CARQUEST 85381
EXMAN OC12100
EXMAN SFO1F03
FILTRON OP557
GOODWILL OG510
GOODWILL OG510HQ
HENGST H90W25
HONDA 15400PH1F02
HONDA 15400PH1F03
JC PREMIUM B14010PR
JC PREMIUM B1P008PR
KAGER 100024
M FILTER TF24
MANN & HUMMEL W811/80
QUINTON HAZELL QFL0017
SAKURA C1606
SCT SM124
SOFIMA S3243R
UFI 23.243.00
UFI 2324300
VALEO 586060
WILMINK GROUP WG1379096
WILMINK GROUP WG1379109
WILMINK GROUP WG1379120
WILMINK GROUP WG1379130
WIX 51064
WIX WL7107
WIX WL7171
Parameter
Outer Diameter: 76 mm (2.99 inch)
THR:ead Size: M20 x 1.5
Length: 88 mm (3.46 inch)
Gasket OD 63 mm (2.48 inch)
Gasket ID 59 mm (2.32 inch)
Efficiency 50% 15 micron
Efficiency 95% 30 micron
Efficiency 99% 35 micron
Efficiency Beta 75 35 micron
Efficiency Test Std: ISO 4548-12, JIS D 1611
Bypass Valve Yes
Bypass Valve Setting LR: 0.76 bar (11 psi)
Bypass Valve Setting HR: 1.2 bar (17 psi)
Media Type: Cellulose
Collapse Burst 6.9 bar (100 psi)
Type: Full-Flow
Style: Spin-On
Packaged Dimensions
Packaged Length: 8.38 cm (3.30 inch)
Packaged Width: 8.13 cm (3.20 inch)
Packaged Height: 9.91 cm (3.90 inch)
Packaged Weight: 0.32 kg (0.72 lb)
Packaged Volume: 0.00 m3 (0.02 ft3)
