Description
Cross Reference
ALDAIR DSL3768
ATLAS COPCO 16164656
ATLAS COPCO 1616465600
ATLAS COPCO 16165151
ATLAS COPCO 16194656
ATLAS COPCO 1619549800
ATLAS COPCO 1626032300
ATLAS COPCO 29110016
ATLAS COPCO 2911001600
ATLAS COPCO 2911002000
ATLAS COPCO 49335210
BALDWIN OAS99008
DONALDSON P530755
DRYTEC MSD1116
FLAM SU1209
FLEETGUARD AS2203
FLEETGUARD AS2442
FLEETGUARD INDIA FT10006
FLUITEK FLK1601781
FRAD 1311443910
GREEN FILTER KUZEY GA6009S
HIFI FILTER OT4656
IMPREFIL IS6120
KELTEC KV100028
KELTEC KV280006
MANN & HUMMEL 4900352141
MANN 4900352141
MANN 4930352101
MDF SARL MDAOS7203
NOITECH NS002730
OXFIL SP3027
PRO FILTERS DST2735
SF FILTER DC3027
SF FILTER SAO58950
VMC AS530755
WOODGATE WGOS4656
Parameter
Outer Diameter: 263.7 mm (10.38 inch)
Inner Diameter: 200.2 mm (7.88 inch)
Length: 362 mm (14.25 inch)
Flange Diameter: 400 mm (15.75 inch)
Bolt Hole Diameter: 22 mm (0.87 inch)
Bolt Hole Circle Diameter: 354 mm (13.94 inch)
Number of Bolt Holes 16
Packaged Dimensions
Packaged Length: 41.91 cm (16.50 inch)
Packaged Width: 41.66 cm (16.40 inch)
Packaged Height: 38.86 cm (15.30 inch)
Packaged Weight: 6.88 kg (15.15 lb)
Packaged Volume: 0.07 m3 (2.40 ft3)
