Description
Cross Reference
AC DELCO PF2157
ALASKA DIESEL ELECTRIC 2405701
ALCOA MARINE KO1568
AMC KO 1568
AMERICAN MOTORS CORPORATION KO1568
AMERICAN PARTS 92444
ASAHI KO 1568
ASAHI KO1568
ATLAS COPCO 2900 5120 00
ATLAS COPCO 29005120
ATLAS COPCO 2900512000
ATLAS COPCO 6136515120
BALDWIN B7223
BALDWIN BT402
BEML 30Z5180495
BENGBU RATA JX1011
BERGERAT MONNOYEUR E6620
BIG A 92444
CARQUEST 85444
CATERPILLAR 3I1482
CATERPILLAR 5W3407N
CHINA LOCAL JX1011B
CHINA LOCAL JX1012
CHINA LOCAL JX1013A
COOP FF1106M
COOPERS LSF5016
DAI ICHI PC212
DONALDSON P550086
FIAAM FT5004
FLEETGUARD LF3664
FLEETRITE LFR 83362
FRAM PH4804
GENERAL MOTORS 25177014
GREYFRIARS 9009S
GUD Z210
HASTINGS HF721
HASTINGS LF406
HASTINGS LF559
JAPANPARTS JFO199
JCB 1132401600
JCB KBP0722
KOBELCO VA32G4001100J1M
KOBELCO VA3424011101
KOMATSU 613615120
KOMATSU 6136515120
KOMATSU 6136515121
KOMATSU 613651520
KRALINATOR L227
LIUGONG SP101847
LIUGONG SP110636
LOESING 025005
LOESING 25005
LPM 2501 101041
LUBER FINER LFP5120B
MITSUBISHI 3254001600
MITSUBISHI 3254021600
MITSUBISHI 32G4001100
MITSUBISHI 3424011101
MOTORCRAFT CFL817
NAPA 1444
NEW HOLLAND VA3424011101
NORTHERN LIGHTS 2405701
ONAN 1220744
P.B.R. BC1179
PUROLATOR L54514
QAP FILTERS WT540001
SANY 60176476
SANY 60176476P
SDLG 4110001060122
SOFIMA SFS06127
SOFIMA SFS0620
SURE FILTER SFO5120
SURE FILTER SFO5121
TFMC T50512
UNITED CENTRAL INDUSTRIAL SUPP 688216
VIC C212
VMC LF550086
WALGAHN MOTORENTECHN 00811816
WALGAHN MOTORENTECHN 811816
WIX 51444
WOODGATE WGL3362
YUCHAI 1501012240
YUCHAI 6401012210
YUCHAI 6401012210A
YUCHAI 6401012240
YUCHAI JX1011B
YUCHAI M30001012240A
YUCHAI YJX6135
Parameter
Outer Diameter: 108 mm (4.25 inch)
THR:ead Size: 1 1/8-16 UN
Length: 167 mm (6.57 inch)
Gasket OD 99 mm (3.90 inch)
Gasket ID 90 mm (3.54 inch)
Efficiency 50% 20 micron
Efficiency Test Std: ISO 4572
Bypass Valve Yes
Bypass Valve Setting LR: 1.8 bar (26 psi)
Bypass Valve Setting HR: 2.1 bar (30 psi)
Media Type: Cellulose
Collapse Burst 10 bar (145 psi)
Type: Full-Flow
Style: Spin-On
Primary Application KOMATSU 6136515120
Packaged Dimensions
Packaged Length: 10.90 cm (4.29 inch)
Packaged Width: 10.90 cm (4.29 inch)
Packaged Height: 16.84 cm (6.63 inch)
Packaged Weight: 1.03 kg (2.28 lb)
Packaged Volume: 0.00 m3 (0.10 ft3)
