Description
Cross Reference
BALDWIN BF1283
BIG A 95446
CARQUEST 86446
CARQUEST 96282
CATERPILLAR 3913764
CATERPILLAR 3I1318
DONALDSON P551746
FLEETGUARD FS19578
FLEETGUARD FS19590
FLEETRITE FSR819574
FRAM PS6834
FRAM PS8450
FREIGHTLINER DNP555060
Freightliner DNP555060
GRADALL 77383819
GREY 8795
HAS FF1181
HASTINGS FF1181
HENGST H7120WK30
HIFI FILTER SN920602
INGERSOLL RAND 89303002
LOESING 025029
LOESING 25029
LUBER FINER LFF8707U
LUBER FINER LFF906
MANITOWOC 4136370
NAPA 3446
ORENSTEIN & KOPPEL 1450138
RACOR R120FG03
RACOR S3206
SAKURA SFC550130
SCHUPP SK3498
TEREX G6450540
WIRTGEN 119393
WIX 33446
WOODGATE WGFS1293
Parameter
Outer Diameter: 111.3 mm (4.38 inch)
THR:ead Size: 1-14 UN
Length: 217.6 mm (8.57 inch)
Gasket OD 74 mm (2.91 inch)
Gasket ID 62.74 mm (2.47 inch)
Bowl THR:ead 3 3/4-10 UN
Efficiency 50% 3 micron
Efficiency Test Std: SAE J1985
Emulsified H2O Efficiency 95 Percent
Collapse Burst 5.2 bar (75 psi)
Type: Water Separator
Style: Spin-On
Media Type: Cellulose
Primary Application RACOR S3206
Packaged Dimensions
Packaged Length: 11.00 cm (4.33 inch)
Packaged Width: 11.00 cm (4.33 inch)
Packaged Height: 22.00 cm (8.66 inch)
Packaged Weight: 0.79 kg (1.73 lb)
Packaged Volume: 0.00 m3 (0.09 ft3)
