Description
Parameter
Length: 300.74 mm (11.84 inch)
Height: 162.56 mm (6.40 inch)
Inlet Size: 1 1/2 SAE 4 Bolt Code 61
Outlet Size: 1 1/2 SAE 4 Bolt Code 61
Filter-to-Head THR:ead 1 3/4-12 UN (x2)
Bypass Valve Yes
Bypass Valve Setting LR: 3.4 bar (49 psi)
Series HMK05/25
Brand: Duramax®
Packaged Dimensions
Packaged Length: 18.03 cm (7.10 inch)
Packaged Width: 12.19 cm (4.80 inch)
Packaged Height: 33.27 cm (13.10 inch)
Packaged Weight: 7.87 kg (17.33 lb)
Packaged Volume: 0.01 m3 (0.26 ft3)
