Description
Cross Reference
LHA TM25100RV5
WIX FILTERS F34C150B5
Parameter
Mesh Rating 150 micron
Outer Diameter: 53.85 mm (2.12 inch)
THR:ead Size: 1 1/4 NPT
Length: 229.62 mm (9.04 inch)
Efficiency Beta 2 149 micron
Bypass Valve Yes
Bypass Valve Setting LR: 0.4 bar (6 psi)
Style: Strainer
Media Type: Wire Mesh
Packaged Dimensions
Packaged Length: 8.13 cm (3.20 inch)
Packaged Width: 6.86 cm (2.70 inch)
Packaged Height: 25.65 cm (10.10 inch)
Packaged Weight: 0.50 kg (1.11 lb)
Packaged Volume: 0.00 m3 (0.05 ft3)
