Description
Cross Reference
HIFI FILTER SH66215
WESTERN EM502B4R03
Parameter
Filter Note Water Glycol Compatibility with Fluorocarbon Seals
Outer Diameter: 119.4 mm (4.7 inch)
THR:ead Size: 1 3/4-12 UN
Length: 361.69 mm (14.24 inch)
Gasket OD 86 mm (3.39 inch)
Gasket ID 79 mm (3.11 inch)
Efficiency Beta 1000 4 micron
Flow Direction Standard
Style: Spin-On
Series HMK05/25
Brand: Duramax®
Media Type: Synthetic
Packaged Dimensions
Packaged Length: 13.21 cm (5.20 inch)
Packaged Width: 12.95 cm (5.10 inch)
Packaged Height: 37.85 cm (14.90 inch)
Packaged Weight: 2.31 kg (5.08 lb)
Packaged Volume: 0.01 m3 (0.23 ft3)
