Description
Cross Reference
ARGO 7242025 P566246 standard capacity；P566256 high capacity
ARGO 7253757 P566246 standard capacity；P566256 high capacity
BALDWIN H8013
BALDWIN H9013
BOSCH REXROTH R928016705
CARQUEST 85295
DENISON DE0411V8C05
DIAGNETICS LPG539V06
DIAGNETICS LPH539V06
DONALDSON P164578
DONALDSON P167836
DONALDSON P171047
DONALDSON P171048
DONALDSON P179749
DONALDSON P566245
DONALDSON P566246
DONALDSON P566254
DONALDSON P566256
DONALDSON P568045
EPPENSTEINER 168300XH6SLS000V
EPPENSTEINER 168300XH6XLS000V
FLEETGUARD HF30143
FLEETGUARD HF30632
FLEETGUARD HF30634
FLEETGUARD HF7008
FLEETGUARD HF7009
GRAINGER 52YR94
HASTINGS H9013
HIFI FILTER SH87029
HILCO 386012043C
HILCO PH73912CG standard capacity；P566256 high capacity
LUBER FINER LH4259
PTI P83250HFB
PTI P83250HFV
SWIFT SF8300396UMV
VICKERS V0411B8C05
VICKERS V0411V8C05
VICKERS V0411V8V05
WIX 51295
Parameter
Seal Material Viton
Outer Diameter: 151.4 mm (5.96 inch)
Inner Diameter: 103.9 mm (4.09 inch)
Length: 981.7 mm (38.65 inch)
Efficiency Beta 1000 8 micron
Collapse Burst 10.3 bar (149 psi)
Flow Direction Outside-In
Style: Cartridge
Series W041
Brand: DT High-Performance
Media Type: Synthetic
Packaged Dimensions
Packaged Length: 18.03 cm (7.10 inch)
Packaged Width: 18.03 cm (7.10 inch)
Packaged Height: 103.12 cm (40.60 inch)
Packaged Weight: 6.51 kg (14.35 lb)
Packaged Volume: 0.03 m3 (1.18 ft3)
