Description
5um version P566261
12um version P566263
23um version P566264
Cross Reference
BEHRINGER BE83141603A
BOSCH 168304UH6XLS000M
DENISON DE2683B5E05
DENISON DE2683V5E05
DONALDSON P566262
EPE 168304UH6SLS000P
EPE 168304UH6XLS000M
EPE 168304UH6XLS000P
FINN FILTER FC1302QE05BK
FLEETGUARD HF30870
HIFI FILTER SH87604
HILCO 386012018C
HYDAC 11416D06ECON
HYDAC 1271727
INTERNORMEN 0583046VG10BP16
PALL HC8304FCN16H
PALL HC8304FDN16H
PALL HC8304FKN16H
PALL HC8304FUN16H
PARKER 937165Q
PARKER 938722Q
PTI PC83150HFB
PTI PC83150HFV
SF FILTER HY20932
SWIFT SF8314166UM
SWIFT SF8314166UMV
Parameter
Seal Material Viton
Outer Diameter: 152.4 mm (6 inch)
Inner Diameter: 95.7 mm (3.77 inch)
Overall Length: 367.8 mm (14.48 inch)
Efficiency Beta 1000 8 micron
Collapse Burst 10.3 bar (149 psi)
Flow Direction Outside-In
Style: Cartridge
Brand: DT High-Performance
Media Type: Synthetic
Packaged Dimensions
Packaged Length: 16.51 cm (6.50 inch)
Packaged Width: 17.02 cm (6.70 inch)
Packaged Height: 44.70 cm (17.60 inch)
Packaged Weight: 1.44 kg (3.18 lb)
Packaged Volume: 0.01 m3 (0.44 ft3)
