Description
Cross Reference
AONALDSON DT031P25UM
ARGO 7224323
ARGO 7224324
BEHRINGER BE310825AV
FLEETGUARD HF7724
FLEETGUARD HF7725
HY PRO HP310L825MB
KALMAR 9216890007
MP FILTRI MP4052
PALL HC2253FCT8H
PALL HC2253FDT8H
PALL HC2253FKT8H
PALL HC2253FUT8H
PARKER 907234
PARKER G01071
SCHROEDER SBF10007Z25V
SEPARATION TECHNOLOGIES ST7724
Parameter
Seal Material Viton
Outer Diameter: 91.5 mm (3.60 inch)
Inner Diameter: 55.4 mm (2.18 inch)
Outlet Diameter: 63 mm (2.48 inch)
Overall Length: 197.7 mm (7.78 inch)
Efficiency Beta 1000 23 micron
Collapse Burst 10.3 bar (149 psi)
Flow Direction Outside-In
Style: Cartridge
Brand: DT High-Performance
Media Type: Synthetic
Packaged Dimensions
Packaged Length: 10.67 cm (4.20 inch)
Packaged Width: 10.67 cm (4.20 inch)
Packaged Height: 25.15 cm (9.90 inch)
Packaged Weight: 0.65 kg (1.43 lb)
Packaged Volume: 0.00 m3 (0.10 ft3)
