Description
Cross Reference
ALCO FILTERS SP1304
AMMANN 49502000402
ASAS SP576
AVELING BARFORD ABP3001583 Short gap version
BALDWIN BT8830
BERGERAT MONNOYEUR E6814 Short gap version
BOBCAT 234099
BOBCAT 2370631
BOBCAT 246262
BOBCAT 247051
BOMAG 31901320 Short gap version
CARQUEST 85474
CASE/CASE IH 146735 Short gap version
CASE/CASE IH 84550621 Short gap version
CASE/CASE IH 87214 Short gap version
CASE/CASE IH D146735 Short gap version
CASE/CASE IH D87214 Short gap version
CATERPILLAR 3I1980 Short gap version
CATERPILLAR 814780 Short gap version
CLAAS 322998 Short gap version
CLAAS 3229980
CLARK 119936862 Short gap version
CLARK 234099 Short gap version
CLARK 2370631
CLARK 246262 Short gap version
CLARK 247050
CLARK 247051 Short gap version
CLARK 6247050
CLARK 8106 Short gap version
CLARK,J.L. 234099 Short gap version
CLARK,J.L. 246262 Short gap version
CLARK,J.L. 247051 Short gap version
CLARKE 247050 Short gap version
CM FILTER CMH4022
COOPERS HSM6182
DANA 10058664
DANA 247050
DANA SPICER 10058664
DANA SPICER 247050
DONALDSON P574731
EUCLID 11992886 Short gap version
EUCLID 11993686 Short gap version
EUCLID 2340990 Short gap version
FENWICK 19982301 Short gap version
FIAT 73118171 Short gap version
FIAT 79104646 Short gap version
FIAT 906041007 Short gap version
FLEETGUARD HF6331
FLEETGUARD HF6420
GRADALL 90204732 Short gap version
GREYFRIARS HS7634 Short gap version
GREYFRIARS HS7639 Short gap version
HAMM 281875
HASTINGS HF701
HEDEN 29802075 Short gap version
HENGST HY377W
HIFI FILTER SH56470
HITACHI 73118171 Short gap version
HITACHI 906041007 Short gap version
HOIST LIFTTRUCK MANUFACTURING P00052
IMPERIAL CV102708
INGERSOLL RAND 58886136 Short gap version
INTRUPA 83285 Short gap version
INTRUPA IF4037 Short gap version
JCB 04110147 Short gap version
JCB 246262 Short gap version
JCB 4110147 Short gap version
JLG 70010839
JLG 90204732 Short gap version
KALMAR 9210280004 Short gap version
KALMAR 9210970002 Short gap version
KALMAR 9234580449 Short gap version
KOEHRING 8320254
KOMATSU 9831967
LOESING 20527
LUBER FINER LFH8799
MACLEAN ENGINERING & MKTG. CO. 1010385 Short gap version
MANITOU 108668 Short gap version
MATCH 101FL1186
MATCH 18819876
MCCORMICK MCD146735 Short gap version
MDF MDH3503
MDF MDH4267
NEW HOLLAND 73118171
NEW HOLLAND 906041007
NORMET 56041494
ORENSTEIN & KOPPEL 8004659
PERFIL PH6046
PRO FILTERS DH850
PUREX SF2850
SAKURA HC7913
SAMPIYON CS0007H
SANDVIK 55071761
SF FILTER SPH9250
SYSTEMS MATERIAL HANDLING CL247050 Short gap version
TAMROCK 04697505
TAMROCK 4697505
TAMROCK 85187419 Short gap version
TAMROCK 88308129 Short gap version
TEHO 4146
TOTAL SOURCE SY86387
UNIFLUX FILTERS XH118
UNITED CENTRAL INDUSTRIAL SUPP 323264 Short gap version
UP LIFTING VERTICAL S.A. 5490060009
VME 11992886 Short gap version
VME 11993686 Short gap version
VME 119936862 Short gap version
VME 2340990 Short gap version
VOLVO 11992886 Short gap version
VOLVO 11993686 Short gap version
VOLVO 119936862 Short gap version
VOLVO 234099 Short gap version
VOLVO 2340990 Short gap version
VOLVO 247050 Short gap version
VOLVO 4720309 Short gap version
WISMET WHS46019
WIX 51474
WIX 551474
WOODGATE WGH6420
Parameter
Outer Diameter: 97.03 mm (3.82 inch)
THR:ead Size: 2-16 UN
Length: 138.78 mm (5.46 inch)
Gasket OD 70.15 mm (2.76 inch)
Gasket ID 63.1 mm (2.48 inch)
Efficiency Beta 1000 23 micron
Bypass Valve Yes
Bypass Valve Setting LR: 1.5 bar (22 psi)
Flow Direction Outside-In
Media Type: Synthetic
Style: Spin-On
Packaged Dimensions
Packaged Length: 10.92 cm (4.30 inch)
Packaged Width: 10.67 cm (4.20 inch)
Packaged Height: 17.02 cm (6.70 inch)
Packaged Weight: 0.84 kg (1.85 lb)
Packaged Volume: 0.00 m3 (0.07 ft3)
