Description
Cross Reference
BOBCAT 6692337
DONALDSON P575347
HENGST EY1166H
HIFI FILTER SH51504
JCB (J.C BamFORD) 334C3974
SAKURA H88110
SF FILTER HY90632
Parameter
Outer Diameter: 72 mm (2.83 inch)
Inner Diameter: 27.9 mm (1.10 inch)
Length: 121.4 mm (4.78 inch)
Gasket OD 32.05 mm (1.26 inch)
Gasket ID 24.99 mm (0.98 inch)
Overall Length: 124.2 mm (4.89 inch)
Efficiency Beta 200 11.5 micron
Efficiency Beta 1000 15 micron
Efficiency Test Std: ISO 16889
Bypass Valve Setting HR: 4.14 bar (60 psi)
Collapse Burst 10.3 bar (149 psi)
Flow Direction Outside-In
Maximum Operating Temperature 107 °C (225 °F)
Style: Cartridge
Media Brand: Synteq XP™
Primary Application BOBCAT 6692337
Packaged Dimensions
Packaged Length: 9.14 cm (3.60 inch)
Packaged Width: 8.64 cm (3.40 inch)
Packaged Height: 14.22 cm (5.60 inch)
Packaged Weight: 0.22 kg (0.49 lb)
Packaged Volume: 0.00 m3 (0.04 ft3)
