Description
Cross Reference
BALDWIN OB1314
CATERPILLAR 3I1477
DONALDSON P167849
DONALDSON P563268
DONALDSON P576557
GRADALL VA30060004
HIFI FILTER DAR23850WD
NAPA 4759
WIX 24759
Parameter
Length: 136.8 mm (5.39 inch)
Height: 94 mm (3.70 inch)
Inlet Size: 1 1/4 NPT
Outlet Size: 1 1/4 NPT
Filter-to-Head THR:ead 1 1/4 BSP/G & 1 1/2-16 UN
Bypass Valve Yes
Bypass Valve Setting LR: 1.72 bar (25 psi)
Series SP50/60
Packaged Dimensions
Packaged Length: 14.73 cm (5.80 inch)
Packaged Width: 14.73 cm (5.80 inch)
Packaged Height: 10.92 cm (4.30 inch)
Packaged Weight: 0.95 kg (2.10 lb)
Packaged Volume: 0.00 m3 (0.08 ft3)
