Description
Use With CLAMP P115205
Cross Reference
BAUDOUIN X6016000
BUCYRUS 3731203
DEUTZ 04228706
DEUTZ 04228706EC016522
DEUTZ 4228706
FLEETGUARD AF27877
FLEETGUARD AH8899
HIFI FILTER SAB085056
IVECO 8046915
LINDENBERG ANLAGEN 20400
LINDENBERG ANLAGEN SERS51083010016
LOESING 020568
LOESING 020882
LOESING 20568
LOESING 20882
MAN 51083010015
MAN 51083010016
MAN 51083040015
MAN 51084016012
MTU 0180941402
PACCAR Y06022706
SAKURA AH7905
SCANIA 1529410
SCHUPP SL5928
SF FILTER SL5928
WEICHAI 1004738348
Parameter
Outlet Diameter: 150 mm (5.91 inch)
Body Diameter: Maximum 196 mm (7.72 inch)
Body Length: 260 mm (10.24 inch)
Efficiency 99.6%
Efficiency Test Std: ISO 5011
Rated Flow LR: 27.5 m³/min (971 cfm)
Rated Flow MR: 34.4 m³/min (1215 cfm)
Rated Flow HR: 40 m³/min (1413 cfm)
Restriction: LR: 10 mbar (4.02 inch H2O)
Restriction: MR: 14.91 mbar (5.98 inch H2O)
Restriction: HR: 19.91 mbar (7.99 inch H2O)
Family: ECB
Primary Application MAN 51083040015
Type: Primary
Style: Round
Brand: DuraLite™
Packaged Dimensions
Packaged Length: 21.01 cm (8.27 inch)
Packaged Width: 21.01 cm (8.27 inch)
Packaged Height: 32.99 cm (12.99 inch)
Packaged Weight: 1.44 kg (3.16 lb)
Packaged Volume: 0.01 m3 (0.51 ft3)
